Data Sheet

General Specifications

Features

• 11-pin plug-in.
• Fail-to-safe design.
• Programmable for overspeed or underspeed monitoring.
• Programmable speed ranges: 10RPM to 10 000RPM.
• Speed setpoint adjustable on calibrated scale (10 to 100%).
• Pulse frequency to current conversion (0-1mA).
• Direct interface with Rhomberg & other Namur two-wire proximity sensors.
• Low power sensor signal to DIN 19234.
• Sensor or cable fault indication.
• Fixed start-up delay 10 sec.
• LED indication of Sensing, Relay ON and cable fault.
• 10A SPDT relay output.
• Requires optional S3-B 11-pin base.
